Litter-Robot EVO: Waste drawer assembly and disassembly guide

The Litter-Robot EVO Waste Drawer is designed for simple assembly, removal, and cleaning. Follow the steps below to correctly attach and detach the waste drawer components.

Before you start

Parts required

• Waste drawer body
• Waste drawer front and step
• Waste drawer liner

Assembling the waste drawer

1. Pull the waste drawer body out from the unit.

2. Place the drawer body on the edge of a table and insert the two hooks and two tabs on the drawer front in the designated slots.

3. Firmly hold the drawer body in place while pressing down on the step and drawer front until they latch into place.

4. Confirm the two hooks on either side of the bottom of the drawer are fully inserted.



5. Confirm that the two center snaps on each side of the drawer (where the drawer body attaches to the drawer front) are secure in the designated slots.

   1. If the center snap is not visibly seated in the slot, press down harder on the tabs on the bottom of the drawer until these are fully inserted.

Note: When properly assembled, the drawer front will protrude slightly over the edge of the drawer body.

6. Insert the drawer liner and smooth it flat against the sides and bottom to ensure proper operation of the Drawer Full Indicator (DFI).

7. Check the inside of the base for any obstructions, such as wires or packaging, before reinstalling the waste drawer.

8. Reinsert the drawer and press the Cancel button.


 Successful assembly:
 The waste drawer should slide smoothly into the unit with the drawer front fully secured and the liner properly installed.

Unsuccessful assembly: If large gaps remain around the top or sides of the drawer after reinserting it into the unit, repeat steps 2–7 to confirm the drawer is assembled correctly.

Disassembling the waste drawer

To remove the step from the drawer body:

1. Flip the waste drawer upside down.

2. While holding the drawer body steady, pull the drawer front upward and away from the drawer body. Firmly, slide the hooks up and outward to unhook them from both sides of the drawer body.

3. Continue pulling upward and away to fully separate the two pieces.
